haxeui-kha

haxeui-kha is the Kha backend for HaxeUI.

Installation

haxeui-kha has a dependency to haxeui-core, and so that too must be installed. Once haxeui-core is installed, haxeui-kha can be installed using:

haxelib install haxeui-kha

Kha

haxeui-kha also has a dependancy on Kha, this can be installed in an empty directory via git using the following commands:

git init
git submodule add https://github.com/KTXSoftware/Kha
git submodule update --init --recursive

Usage

The simplest method to create a new Kha application that is HaxeUI ready is to use the HaxeUI command line tools. These tools will allow you to start a new project rapidly with HaxeUI support baked in. To create a new skeleton application using haxeui-kha run the following command in the folder where Kha has been installed:

haxelib run haxeui-core create kha

If however you already have an existing application, then incorporating HaxeUI into that application is straightforward:

khamake.js

Simply add the following lines to your khamake.js and rebuild your project files.

project.addLibrary('haxeui-core');
project.addLibrary('haxeui-kha');
project.addLibrary('hscript');

Toolkit initialisation and usage

The Kha system itself must be initialised and a render loop started. This can be done by using code similar to:

class Main {
    public static function main() {
        kha.System.start({}, function ( _ ) {
            kha.Assets.loadEverything(function() {
                haxe.ui.Toolkit.init();

                final screen = haxe.ui.core.Screen.instance;
                final ui = haxe.ui.macros.ComponentMacros.buildComponent("ui.xml");

                screen.addComponent(ui);

                kha.System.notifyOnFrames(function( framebuffers: Array ) {
                    final fb = framebuffers[0];
                    final g2 = fb.g2;
                    g2.begin(true, kha.Color.White);
                        screen.renderTo(g2);
                    g2.end();
                });
            });
        });
    }
}

Once the toolkit is initialised you can add components using the methods specified here.

Kha specifics

As well as using the generic Screen.instance.addComponent, it is also possible to render a component to a specific surface use the components special renderTo function. Eg:

main.renderTo(...);
